Fiat 580
Contents:
Production | |
| Manufacturer: | Fiat |
Fiat 580 Power | |
| Engine: | 58 hp 43.3 kW |
| PTO (claimed): | 50 hp 37.3 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| 4x4 MFWD 4WD | |
| Final drives: | planetary |
| Steering: | power |
| Brakes: | hydraulic wet disc |
| Cab: | Four-post ROPS. Cab optional with available air-conditioning. |
| Transmissions: | 8-speed partially synchronized |
| 12-speed | |
| 8-speed mechanical shuttle | |
| 16-speed creeper | |
Hydraulics | |
| Pump flow: | 7.4 gpm 28.0 lpm |
Tractor hitch | |
| Rear Type: | II/I |
| Rear lift: | 5292 lbs 2400 kg |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Rear RPM: | 540 (1.375) |
| Engine RPM: | 540@2314 |
Electrical | |
| Ground: | negative |
| Charging system: | alternator |
| Charging amps: | 33 |
| Battery volts: | 12 |
Engine Detail | |
| Fiat 8035 | |
| diesel | |
| 3-cylinder | |
| liquid-cooled | |
| Displacement: | 167.8 ci 2.8 L |
| Bore/Stroke: | 4.05x4.33 inches 103 x 110 mm |
| Power: | 58 hp 43.3 kW |
| Air cleaner: | dual dry element |
| Compression: | 17:1 |
| Rated RPM: | 2700 |
| Firing order: | 1-2-3 |
| Starter volts: | 12 |
Dimensions | |
| 2WD Wheelbase: | 85.5 inches 217 cm |
| 4WD Wheelbase: | 85 inches 215 cm |
| 2WD Length: | 130.8 inches 332 cm |
| 4WD Length: | 135.2 inches 343 cm |
| 2WD Weight: | 5149 lbs 2335 kg |
| 4WD Weight: | 5766 lbs 2615 kg |
| 2WD Clearance (front axle): | 19 inches 48 cm |
| 4WD Clearance (front axle): | 16.1 inches 40 cm |
| 2WD Front tread: | 55.1 to 74.8 inches 139 to 189 cm |
| 4WD Front tread: | 60.2 to 77 inches 152 to 195 cm |
| Rear tread: | 55.1 to 78.7 inches 139 to 199 cm |
