Fendt Favorit 509C

Production: 1994 - 1999

Production
Manufacturer:	Fendt

Fendt Favorit 509C Power
Engine:	95 hp 70.8 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Differential lock:	electro-hydraulic front and rear
Steering:	power
Brakes:	hydraulic disc
Cab:	Cab standard with heater. Air-conditioning optional.
Transmission:	44-speed four-speed power shift

Hydraulics
Pump flow:	26.9 gpm 101.8 lpm

Tractor hitch
Rear Type:	III/II
Control:	lower-link draft sensing
Rear lift:	12145 lbs 5508 kg

Power Take-off (PTO)
Rear PTO:	independent
Clutch:	electro-hydraulic
Rear RPM:	540/750/1000/1400
Front PTO:	independent*Optional
Front RPM:	1000

Electrical
Ground:	negative
Charging system:	alternator
Battery volts:	12
Battery AH:	110

Engine Detail
MWM
turbocharged diesel
4-cylinder
liquid-cooled
Displacement:	253.5 ci 4.2 L
Bore/Stroke:	4.13x4.72 inches 105 x 120 mm
Power:	95 hp 70.8 kW
Rated RPM:	2300
Torque:	281 lb-ft 381.0 Nm
Torque RPM:	1500
Starter volts:	12

Transmission
Type:	four-speed power shift
Gears:	44 forward and reverse
Four power shift gears (I-IV) in six ranges (1-6) with shuttle. Additional creeper range provides another five ranges.

Dimensions
Wheelbase:	91.9 inches 233 cm
Length:	164.6 inches 418 cm
Width:	82.3 inches 209 cm
Height (cab):	110 inches 279 cm
Weight:	10957 lbs 4970 kg
Max weight:	16535 lbs 7500 kg
Ground clearance:	21.1 inches 53 cm
Front tread:	59.1 to 74.8 inches 150 to 189 cm
Rear tread:	59.1 to 74.8 inches 150 to 189 cm
