Fendt Farmer 1E

Production: 1967 - 1971

Production
Manufacturer:	Fendt

Fendt Farmer 1E Power
Engine:	30 hp 22.4 kW

Mechanical
Transmission:	6-speed

Tractor hitch
Rear lift:	3307 lbs 1500 kg

Power Take-off (PTO)
Rear RPM:	540

Engine Detail
MWM
diesel
2-cylinder
Displacement:	103.73 ci 1.7 L
Bore/Stroke:	3.7402x4.72 inches 95 x 120 mm
Power:	30 hp 22.4 kW
Rated RPM:	2275

Transmission
Gears:	6 forward and 2 reverse

Dimensions
Wheelbase:	73.62 inches 186 cm
Length:	125.20 inches 318 cm
Height:	86.61 inches 219 cm
Weight:	3550 lbs 1610 kg
