hydraulic disc*Disc brakes on front axle, drums on rear axle.
Cab:
Cab standard with heater.
Transmission:
21-speed
Hydraulics
Pressure:
2611 psi 180.0 bar
Pump flow:
10.6 gpm 40.1 lpm
Total flow:
18 gpm 68.1 lpm
Steering flow:
7.4 gpm 28.0 lpm
Tractor hitch
Rear Type:
II
Rear lift:
9656 lbs 4379 kg
Front Hitch:
II
Front lift:
4811 lbs 2182 kg
Power Take-off (PTO)
Rear PTO:
independent
Rear RPM:
540/750
540/1000*Optional. Not available with creeper transmission.
Front PTO:
independent
Front RPM:
1000
Electrical
Charging system:
alternator
Charging amps:
55
Charging volts:
14
Battery AH:
110
Engine Detail
KHD
diesel
4-cylinder
air-cooled
Displacement:
230.1 ci 3.8 L
Bore/Stroke:
3.94x4.72 inches 100 x 120 mm
Power:
65 hp 48.5 kW
Rated RPM:
2300
Torque:
174.8 lb-ft 237.0 Nm
Torque RPM:
1600
Starter type:
electric
Transmission
Gears:
21 forward and 6 reverse
Three gears (1-3) plus reverse (R) in two ranges with three-speed electric over/under shift. An additional three overdrive speeds are available on the gear shift.
