Fendt 207

Production: 2003 - 2009

Production
Manufacturer:	Fendt (a part of AGCO)
Type:	Utility tractor

Variants

utility

ultra-narrow

narrow

Fendt 207 Power
Engine (gross):	71.1 hp 53.0 kW
Engine (net):	68.4 hp 51.0 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Steering:	power
Brakes:	hydraulic disc
Cab:	Cab standard with available heat and air-conditioning.
Transmissions:	21-speed synchromesh
21-speed shuttle

Hydraulics
Type:	open center
Pressure:	2900 psi 200.0 bar
Valves:	2 or 3
Pump flow:	12.4 gpm 46.9 lpm
19.6 gpm 74.2 lpm *Optional

Tractor hitch
Rear Type:	2
Front Hitch:	optional

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	540/750/1000
540/750/ground*Optional
Front PTO:	independent*Optional
Front RPM:	540
1000

Electrical
Ground:	negative
Charging system:	alternator
Charging amps:	95
Charging volts:	14
Battery volts:	12
Battery AH:	88

Engine Detail
Deutz
turbocharged diesel
3-cylinder
air-cooled
Displacement:	197.5 ci 3.2 L
Bore/Stroke:	4.02x5.20 inches 102 x 132 mm
Rated Power (ECE R24):	68.4 hp 51.0 kW
Rated Power (EC 97/98):	71.1 hp 53.0 kW
Rated RPM:	2300
Torque:	194.7 lb-ft 264.0 Nm
Torque RPM:	1500
Starter:	electric
Starter volts:	12

Dimensions
Wheelbase:	82.8 inches 210 cm
Length:	140.4 inches 356 cm
Width:	75.8 inches 192 cm
Height:	97.4 inches 247 cm
Weight:	6460 lbs 2930 kg
Max weight:	11684 lbs 5299 kg
Front tread:	58.8 inches 149 cm
Rear tread:	59.1 inches 150 cm
