Farmall 300
Type: Row-crop Tractors
Contents:
Production | |
| Manufacturer: | Farmall (a part of International Harvester) |
| Type: | Row-Crop tractor |
| Total built: | 29,077 |
| 170 (High-Clearance) | |
| Original price: | $2,900 (1956 ) |
Variants | |
| utility tractor | |
| Farmall 300 High-Clearance: | high-crop tractor |
Farmall 300 Power | |
| Plows: | 3-bottom |
| Drawbar (tested): | 35.43 hp 26.4 kW |
| Belt (tested): | 38.42 hp 28.6 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| Cab: | Open operator station. |
| Transmissions: | 5-speed sliding gear |
| 10-speed partial power shift | |
Tractor hitch | |
| Type: | IH Fast Hitch |
Power Take-off (PTO) | |
| Rear RPM: | 540 |
300 Serial Numbers | |
| Location: | Serial number on the left side of the clutch housing. |
| 1954: | 501 |
| 1955: | 1779 |
| 1956: | 23224 |
Electrical | |
| Ground: | positive |
| Battery volts: | 6 |
Engine Detail | |
| International Harvester C169 | |
| gasoline | |
| 4-cylinder | |
| liquid-cooled | |
| Displacement: | 169 ci 2.8 L |
| Bore/Stroke: | 3.5625x4.25 inches 90 x 108 mm |
| Air cleaner: | oil bath |
| Compression: | 6.6:1 |
| Rated RPM: | 1750 |
| Starter volts: | 6 |
| Coolant capacity: | 16.5 qts 15.6 L |
Dimensions | |
| Wheelbase: | 92.25 inches 234 cm (tricycle) |
| 96 inches 243 cm (wide-front) | |
| Length: | 136 inches 345 cm (tricycle) |
| 140 inches 355 cm (wide-front) | |
| Width: | 100 inches 254 cm |
| Height (steering wheel): | 77 inches 195 cm |
| 88 inches 223 cm (high-clearance) | |
| Weight: | 5361 lbs 2431 kg |
