Farmall 1466

Production
Manufacturer:	Farmall (a part of International Harvester)
Type:	Row-Crop tractor
Total built:	25,264
Original price:	$23,600 (1976)

Farmall 1466 Power
PTO (claimed):	133 hp 99.2 kW
Drawbar (tested):	123.20 hp 91.9 kW
PTO (tested):	145.77 hp 108.7 kW

Mechanical
Chassis:	4x2 2WD
4x4 MFWD 4WD
Steering:	hydrostatic power
Brakes:	independent hydrostatic dry disc
Cab:	Cab optional with heat and A/C
Transmissions:	8-speed
16-speed

Capacity
Fuel:	42 gal 159.0 L
Hydraulic system:	22 gal 83.3 L

Hydraulics
Type:	open center
Capacity:	22 gal 83.3 L
Pressure:	2000 psi 137.9 bar
Valves:	1
Pump flow:	12 gpm 45.4 lpm
Total flow:	24 gpm 90.8 lpm
Steering flow:	9 gpm 34.1 lpm
Steering press.:	1550 psi 106.9 bar

Tractor hitch
Rear Type:	3/2
Rear lift (at 24"/610mm):	5,600 lbs 2540 kg

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	1000

1466 Serial Numbers
Location:	Clutch housing, left side
1971:	7101
1972:	10408
1973:	15533
1974:	19746
1975:	25404
1976:	29516

Electrical
Charging amps:	32
Batteries:	2
Battery volts:	6
Battery AH:	172

Engine Detail
International Harvester DT-436
turbocharged diesel
6-cylinder
liquid-cooled
Displacement:	436 ci 7.1 L
Bore/Stroke:	4.30x5.00 inches 109 x 127 mm
Air cleaner:	dual dry elements
Rated RPM:	2400 (early)
2600 (late)
Starter volts:	12
Oil capacity:	18 qts 17.0 L
Coolant capacity:	27 qts 25.6 L

Dimensions
Wheelbase:	105 inches 266 cm
Length:	168 inches 426 cm
Width:	98 inches 248 cm
Height (exhaust):	111 inches 281 cm
Operating weight:	13,480 lbs 6114 kg (with cab)
Ballasted weight:	16,660 lbs 7556 kg
Clearance (drawbar):	16 inches 40 cm
