Dongfeng DF-800
Contents:
Production | |
| Manufacturer: | Dongfeng |
| Factory: | Changzhou, Jiangsu, China |
Variants | |
| 4WD |
Dongfeng DF-800 Power | |
| Engine: | 80 hp 59.7 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| Steering: | hydraulic power |
| Brakes: | wet disc |
| Transmission: | 8-speed |
Power Take-off (PTO) | |
| Rear PTO: | live (2-stage clutch) |
| Rear RPM: | 540/1000 |
| 760/1000 | |
Engine Detail | |
| LR4108T | |
| diesel | |
| 4-cylinder | |
| liquid-cooled | |
| Displacement: | 264.2 ci 4.3 L |
| Bore/Stroke: | 4.252x4.724 inches 108 x 120 mm |
| Power: | 80 hp 59.7 kW |
| Rated RPM: | 2300 |
Transmission | |
| Gears: | 8 forward and 4 reverse |
Dimensions | |
| Wheelbase: | 93.0 inches 236 cm |
| Length: | 180.8 inches 459 cm |
| Width: | 80.7 inches 204 cm |
| Height: | 110.6 inches 280 cm |
| Weight: | 6,880 lbs 3120 kg |
| Ground clearance: | 18.7 inches 47 cm |
