Deutz-Fahr Agrotron X720

Production: 2006 - 2012

Production
Manufacturer:	Deutz-Fahr
Type:	Row-Crop tractor

Deutz-Fahr X720 Power
Engine (gross):	265.5 hp 198.0 kW
Engine (max):	270.8 hp 201.9 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Steering:	power
Brakes:	wet disc
Cab:	Cab standard with air-conditioning.
Transmission:	40-speed

Hydraulics
Type:	load sensing
Pressure:	2901 psi 200.0 bar
Pump flow:	31.7 gpm 120.0 lpm
Steering flow:	15.1 gpm 57.2 lpm
Steering press.:	2683 psi 185.0 bar

Tractor hitch
Rear Type:	III
Rear lift:	23150 lbs 10500 kg
Front Hitch:	II
Front lift:	11020 lbs 4998 kg

Power Take-off (PTO)
Rear PTO:	independent
Clutch:	electro-hydraulic
Rear RPM:	540E/1000
Front PTO:	independent
Clutch:	electro-hydraulic
Front RPM:	1000

Electrical
Charging system:	alternator
Charging amps:	200
Battery volts:	12
Battery AH:	180

Transmission
Gears:	40 forward and reverse
Six synchronized gears (1-6) in four power shift ranges (L/M/H/S) with power shuttle. Additional creeper range with four gears (1-4) in four ranges (L/M/H/S).

Dimensions
Wheelbase:	121.9 inches 309 cm
Length:	212.6 inches 540 cm
Width:	108.3 inches 275 cm
Height (cab):	128.7 inches 326 cm
Weight:	23005 lbs 10435 kg
Max weight:	30865 lbs 14000 kg
