Deutz-Allis 6250

Production: 1986 - 1990

Production
Manufacturer:	Deutz-Allis
Type:	Utility tractor
Factory:	Germany

Variants

utility

narrow

Deutz-Allis 6250 Power
Engine:	54 hp 40.3 kW
PTO (claimed):	51 hp 38.0 kW

Mechanical
Chassis:	4x2 2WD
4x4 MFWD 4WD
Differential lock:	mechanical rear
Steering:	power
Brakes:	mechanical disc
Cab:	Four-post ROPS
Transmissions:	8-speed partially synchronized
16-speed two-speed power shift

Capacity
Fuel:	20 gal 75.7 L
Hydraulic system:	4 gal 15.1 L
7.5 gal 28.4 L *Optional

Hydraulics
Type:	open center
Capacity:	4 gal 15.1 L
7.5 gal 28.4 L *Optional
Pressure:	2538 psi 175.0 bar
Valves:	1 to 3
Pump flow:	5291 gpm 20026.4 lpm

Tractor hitch
Rear Type:	I
Rear lift (at ends):	5291 lbs 2399 kg
Front Hitch:	II
Front lift:	2205 lbs 1000 kg

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	540 (1.375)
Front PTO:	independent
Front RPM:	1000

Electrical
Ground:	negative
Charging system:	alternator
Battery volts:	12

Engine Detail
Deutz F3L 912
diesel
3-cylinder
air-cooled
Displacement:	172 ci 2.8 L
Bore/Stroke:	3.94x4.72 inches 100 x 120 mm
Power:	54 hp 40.3 kW
Rated RPM:	2500
Starter volts:	12
Oil capacity:	8.5 qts 8.0 L

Dimensions
2WD Wheelbase:	79 inches 200 cm
4WD Wheelbase:	82 inches 208 cm
Width:	82.3 inches 209 cm
Height (ROPS):	91.3 inches 231 cm
2WD Weight:	6018 lbs 2729 kg
4WD Weight:	6459 lbs 2929 kg
Rear tread:	59 to 78.8 inches 149 to 200 cm
