Deere 750
Type: Compact Utility Tractors
Contents:
Production | |
| Distributor: | John Deere |
| Manufacturer: | Yanmar |
| Type: | Compact Utility tractor |
| Factory: | Japan |
| Original price: | $10,000 (1989 ) |
John Deere 750 Power | |
| Engine (gross): | 20 hp 14.9 kW |
| PTO (claimed): | 18 hp 13.4 kW |
| Drawbar (tested): | 15.30 hp 11.4 kW |
| PTO (tested): | 18.54 hp 13.8 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| 4x4 MFWD 4WD | |
| Steering: | manual |
| power optional | |
| Brakes: | differential mechanical dry, internal expanding shoe |
| Cab: | Two-post ROPS. |
| Transmission: | 8-speed gear |
Hydraulics | |
| Type: | open center |
| Pressure: | 2030 psi 140.0 bar |
| Valves: | 1 |
Tractor hitch | |
| Rear Type: | I |
Power Take-off (PTO) | |
| Rear PTO: | transmission |
| Clutch: | over-running |
| Rear RPM: | 540 |
| Engine RPM: | 540@2300 |
| Front PTO: | independent*Optional |
| Clutch: | electro-magnetic |
750 Serial Numbers | |
| Location: | Serial number plate on the rear of the John Deere 750, below the PTO shaft. |
| 1981: | 1000 |
| 1982: | 3448 |
| 1983: | 5613 |
| 1984: | 8457 |
| 1985: | 13001 |
| 1986: | 18501 |
| 1987: | 22601 |
| 1988: | 26450 |
| Final: | 28161 |
Electrical | |
| Ground: | negative |
| Battery volts: | 12 |
Engine Detail | |
| Yanmar 3T80 | |
| diesel | |
| 3-cylinder | |
| liquid-cooled inline | |
| Displacement: | 78.2 ci 1.3 L |
| Bore/Stroke: | 3.15x3.35 inches 80 x 85 mm |
| Power (gross): | 20 hp 14.9 kW |
| Air cleaner: | paper element |
| Compression: | 22.5:1 |
| Rated RPM: | 2400 |
| Starter volts: | 12 |
| Oil capacity: | 4.0 qts 3.8 L |
| Coolant capacity: | 4.5 qts 4.3 L |
Transmission | |
| Type: | gear |
| Gears: | 8 forward and 2 reverse |
| Clutch: | 200mm dry disc |
| Oil capacity: | 15 qts 14.2 L |
Dimensions | |
| Wheelbase: | 61.1 inches 155 cm |
| Length: | 112 inches 284 cm |
| Width: | 45.1 inches 114 cm |
| 2WD Shipping weight: | 1900 lbs 861 kg |
| 4WD Shipping weight: | 2000 lbs 907 kg |
| Clearance (front axle): | 15.1 inches 38 cm (2WD) |
| 13 inches 33 cm (4WD) | |
| Front tread: | 35 inches 88 cm (2WD) |
| Front tread: | 36 inches 91 cm (4WD) |
| Rear tread: | 35/39 inches 88/99 cm |
