Deere 6506
Type: Row-crop Tractors
Contents:
Production | |
| Manufacturer: | John Deere |
| Type: | Row-Crop tractor |
| Factory: | Mannheim, Baden-Württemberg, Germany |
John Deere 6506 Power | |
| Engine: | 105 hp 78.3 kW |
Mechanical | |
| Chassis: | 4x4 MFWD 4WD |
| Steering: | power |
| Brakes: | wet disc |
| Cab: | Cab standard. |
| Transmissions: | 20-speed partial power shift |
| 16-speed | |
| 24-speed | |
Hydraulics | |
| Pressure: | 2900 psi 200.0 bar |
| Total flow: | 15.85 gpm 60.0 lpm |
Tractor hitch | |
| Rear lift: | 12,070 lbs 5474 kg |
Power Take-off (PTO) | |
| Rear RPM: | 540/1000 |
Electrical | |
| Ground: | negative |
| Battery volts: | 12 |
Engine Detail | |
| John Deere 6068 | |
| diesel | |
| 6-cylinder | |
| liquid-cooled | |
| Displacement: | 414.1 ci 6.8 L |
| Bore/Stroke: | 4.19x5.00 inches 106 x 127 mm |
| Power: | 105 hp 78.3 kW |
| Rated RPM: | 2300 |
| Torque: | 317.2 lb-ft 430.1 Nm |
| Torque RPM: | 1300 |
| Starter: | electric |
| Starter volts: | 12 |
Dimensions | |
| Wheelbase: | 104.3 inches 264 cm |
| Length: | 177.2 inches 450 cm |
| Height (cab): | 110.6 inches 280 cm |
| Weight: | 10,250 lbs 4649 kg |
