Deere 6175M
Type: Row-crop Tractors
Contents:
Production | |
| Manufacturer: | John Deere |
| Type: | Row-Crop tractor |
| Factory: | Mannheim, Baden-Württemberg, Germany |
John Deere 6175M Power | |
| Engine (gross): | 175 hp 130.5 kW |
| Engine (max): | 185 hp 138.0 kW |
| PTO (claimed): | 142 hp 105.9 kW |
| Drawbar (tested): | 140.4 hp 104.7 kW |
| PTO (tested): | 167.4 hp 124.8 kW |
Mechanical | |
| Chassis: | 4x4 MFWD 4WD |
| Final drives: | inboard planetary |
| Differential lock: | electro-hydraulic front and rear |
| Steering: | power |
| Brakes: | hydraulic wet disc |
| Cab: | Cab standard with air-conditoning. |
| Transmissions: | 16-speed four-speed power shift |
| 20-speed four-speed power shift | |
Hydraulics | |
| Type: | closed-center pressure-and-flow compensated |
| Pressure: | 2900 psi 200.0 bar |
| Rear valves: | 3*Optional |
| Mid valves: | 3*Optional |
| Pump flow: | 30 gpm 113.6 lpm |
| SCV flow: | 26.4 gpm 99.9 lpm |
Tractor hitch | |
| Rear Type: | IIIN/II |
| Control: | electronic lower-link draft sensing |
| Rear lift: | 10696 lbs 4851 kg |
| Drawbar: | Cat. 2 |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Clutch: | electro-hydraulic |
| Rear RPM: | 540/1000 (1.375) |
| 540 | |
| Engine RPM: | 540@1932 1000@1932 |
6175M Serial Numbers | |
| Location: | Serial number plate on the right side of the tractor frame, above and to the rear of the front axle. |
Electrical | |
| Ground: | negative |
| Charging system: | alternator |
| Charging amps: | 120 |
| 200*Optional | |
| Charging volts: | 14 |
| Battery volts: | 12 |
Engine Detail | |
| John Deere PowerTech PVS | |
| turbocharged aftercooled diesel | |
| 6-cylinder 24-valve | |
| liquid-cooled inline | |
| Displacement: | 414 ci 6.8 L |
| Bore/Stroke: | 4.15x5.00 inches 105 x 127 mm |
| Emissions: | Tier IV |
| Emission control: | cooled exhaust-gas recirculation, diesel particulate filter, and selective catalytic reduction |
| Rated Power (EC 97/98): | 175 hp 130.5 kW |
| Maximum Power (EC 97/68): | 185 hp 138.0 kW |
| Rated RPM: | 2100 |
| Starter: | electric |
| Starter volts: | 12 |
| Starter power: | 4 hp 3.0 kW |
| Coolant capacity: | 24.5 qts 23.2 L |
Dimensions | |
| Wheelbase: | 110.2 inches 279 cm |
| Length: | 196.2 inches 498 cm |
| Width: | 100.4 inches 255 cm |
| Height (cab): | 120 inches 304 cm |
| Clearance (front axle): | 23.9 inches 60 cm |
| Rear axle: | Rack-and-pinion: 3.622 by 100.4 inches 91 by 2550 mm |
