Deere 6130R
Type: Utility Tractors
Contents:
Production | |
| Manufacturer: | John Deere |
| Type: | Utility tractor |
| Factory: | Mannheim, Baden-Württemberg, Germany |
John Deere 6130R Power | |
| Engine (gross): | 130 hp 96.9 kW |
| Engine (max): | 141 hp 105.1 kW |
| PTO (claimed): | 101 hp 75.3 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| 4x4 MFWD 4WD | |
| Final drives: | inboard planetary |
| Steering: | power |
| Brakes: | hydraulic wet disc |
| Cab: | Cab standard with air-conditioning. |
| Transmissions: | 16-speed partial power shift |
| 24-speed partial power shift | |
| infinitely variable transmission | |
Hydraulics | |
| Type: | closed center |
| Pressure: | 2900 psi 200.0 bar |
| Valves: | 2 to 4 |
| Pump flow: | 30 gpm 113.6 lpm |
| SCV flow: | 26.4 gpm 99.9 lpm |
Tractor hitch | |
| Rear Type: | II |
| Control: | electronic lower-link draft sensing |
| Rear lift (at 24"/610mm): | 6475 lbs 2937 kg |
| 8457 lbs 3836 kg *Optional | |
| Drawbar: | Cat. 2 |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Clutch: | electro-hydraulic |
| Rear RPM: | 540/1000 |
| 540/540E/1000*Optional | |
6130R Serial Numbers | |
| Location: | Serial number plate on the right side of the tractor frame, above the front axle. |
Electrical | |
| Ground: | negative |
| Charging system: | alternator |
| Charging amps: | 200 |
| 240*Optional | |
| Charging volts: | 14 |
| Battery volts: | 12 |
| Battery AH: | 154 |
Engine Detail | |
| John Deere | |
| turbocharged diesel | |
| 4-cylinder 16-valve | |
| liquid-cooled inline | |
| Displacement: | 276 ci 4.5 L |
| Bore/Stroke: | 4.19x5.00 inches 106 x 127 mm |
| Emissions: | Tier IV |
| Emission control: | selective catalytic reduction and exhaust gas recirculation |
| Rated Power (EC 97/98): | 130 hp 96.9 kW |
| Maximum Power (EC 97/68): | 141 hp 105.1 kW |
| Rated RPM: | 2100 |
| Starter: | electric |
| Starter volts: | 12 |
Dimensions | |
| Wheelbase: | 102 inches 259 cm |
| Clearance (front axle): | 18.5 inches 46 cm |
| Rear axle: | Flange |
| 2WD Front tread: | 58.5 to 96 inches 148 to 243 cm |
| 4WD Front tread: | 63.6 to 75.7 inches 161 to 192 cm |
| Rear tread: | 63.1 to 90.6 inches 160 to 230 cm |
