Deere 6030
Type: Row-crop Tractors
Contents:
Production | |
| Manufacturer: | John Deere |
| Type: | Row-Crop tractor |
| Factory: | Waterloo, Iowa, USA |
| Total built: | 4,028 |
| 3,983 turbo | |
| 45 natural | |
| Original price: | $29,000 (1977 ) |
John Deere 6030 Power | |
| PTO (claimed): | 175 hp 130.5 kW (turbo) |
| 141 hp 105.1 kW (natural) | |
| Drawbar (tested): | 148.70 hp 110.9 kW |
| PTO (tested): | 175.99 hp 131.2 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| Differential lock: | hydraulic-actuated |
| Steering: | power |
| Brakes: | differential hydraulic wet disc |
| Cab: | Open operator station. Cab optional with air-conditioning available. |
| Transmission: | 8-speed partially synchronized |
Capacity | |
| Fuel: | 73 gal 276.3 L |
| Hydraulic system: | 16 gal 60.6 L |
Hydraulics | |
| Type: | closed center |
| Capacity: | 16 gal 60.6 L |
| Valves: | 2 |
| Pump flow: | 22 gpm 83.3 lpm |
Tractor hitch | |
| Rear Type: | III/II |
| Rear lift: | 5910 lbs 2680 kg |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Rear RPM: | 1000 |
6030 Serial Numbers | |
| 1972: | 33000 |
| 1973: | 33550 |
| 1974: | 34586 |
| 1975: | 35400 |
| 1976: | 36014 |
| 1977: | 36577 |
| Final: | 37041 |
Electrical | |
| Ground: | negative |
| Charging system: | alternator |
| Charging amps: | 55 |
| 78*Optional | |
| Batteries: | 2 |
| Battery volts: | 6 |
Engine Detail | |
| John Deere | |
| turbocharged intercooled diesel | |
| 6-cylinder | |
| liquid-cooled inline | |
| Displacement: | 531 ci 8.7 L |
| Bore/Stroke: | 4.75x5.00 inches 121 x 127 mm |
| Air cleaner: | dual paper elements with aspirator |
| Compression: | 15.4:1 |
| Rated RPM: | 2100 |
| Starter volts: | 12 |
| Coolant capacity: | 40 qts 37.9 L |
Transmission | |
| Transmission: | John Deere Syncro-Range |
| Type: | partially synchronized |
| Gears: | 8 forward and 2 reverse |
| Clutch: | dry disc |
Dimensions | |
| Wheelbase: | 104 inches 264 cm |
| Operating weight: | 18,180 lbs 8246 kg |
