Deere 5725
Type: Utility Tractors
Contents:
Production | |
| Manufacturer: | John Deere |
| Type: | Utility tractor |
| Factory: | Saltillo, Mexico |
Variants | |
| 5725O: | orchard |
| 5725HC: | high-crop |
John Deere 5725 Power | |
| Engine: | 89 hp 66.4 kW |
| PTO (claimed): | 77 hp 57.4 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| 4x4 MFWD 4WD | |
| Steering: | power |
| Brakes: | hydraulic wet disc |
| Cab: | Two-post fixed ROPS. Foldable ROPS optional. Optional isolate platform (IOOS). Cab optional with air-conditioning. |
| Transmissions: | 9-speed gear |
| 9-speed partially synchronized | |
| 12-speed power shuttle | |
Hydraulics | |
| Type: | open center |
| Pressure: | 2800 psi 193.1 bar |
| Pump flow: | 15.9 gpm 60.2 lpm |
| Steering flow: | 6.6 gpm 25.0 lpm |
| Steering press.: | 1900 psi 131.0 bar |
Tractor hitch | |
| Rear Type: | II/I |
| Control: | top-link draft sensing |
| Rear lift (at 24"/610mm): | 3374 lbs 1530 kg |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Rear RPM: | 540 (1.375) |
| Engine RPM: | 540@2400 540E@1700 |
5725 Serial Numbers | |
| Location: | Serial number plate on the left side of the tractor frame, above the front axle. |
Electrical | |
| Ground: | negative |
| Charging system: | alternator |
| ROPS Charging amps: | 70 |
| Cab Charging amps: | 90 |
| Battery CCA: | 550 |
| Battery volts: | 12 |
| Battery Group: | 27F |
Engine Detail | |
| John Deere | |
| turbocharged diesel | |
| 4-cylinder | |
| liquid-cooled | |
| Displacement: | 278 ci 4.6 L |
| Bore/Stroke: | 4.19x5.00 inches 106 x 127 mm |
| Emissions: | Tier 0 |
| Power: | 89 hp 66.4 kW |
| Compression: | 17.0:1 |
| Rated RPM: | 2400 |
| Idle RPM: | 800-2600 |
| Operating RPM: | 1600-2400 |
| Firing order: | 1-3-4-2 |
| Starter: | electric |
| Starter volts: | 12 |
| Oil capacity: | 9 qts 8.5 L |
| Coolant capacity: | 11.4 qts 10.8 L |
| Intake valve clearance: | 0.014 inches 0.356 mm |
| Exhaust valve clearance: | 0.018 inches 0.457 mm |
Dimensions | |
| Wheelbase: | 85.8 inches 217 cm |
| OOS Length: | 140.5 inches 356 cm |
| IOOS Length: | 149.5 inches 379 cm |
| Cab Length: | 149.5 inches 379 cm |
| Width: | 82.6 inches 209 cm |
| 2WD Clearance (front axle): | 20 inches 50 cm |
| 4WD Clearance (front axle): | 16.5 inches 41 cm |
