John Deere 5520
Type: Utility Tractors
Contents:
Production | |
| Manufacturer: | John Deere |
| Type: | Utility tractor |
| Factory: | Augusta, Georgia, USA |
| Original price: | $31,000 (2004) |
Variants | |
| utility | |
| narrow chassis | |
| high-crop |
John Deere 5520 Power | |
| Engine: | 89 hp 66.4 kW |
| PTO (claimed): | 75 hp 55.9 kW |
| PTO (tested): | 82.24 hp 61.3 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| 4x4 MFWD 4WD | |
| Steering: | hydrostatic power |
| Brakes: | hydraulic wet disc |
| Cab: | ROPS with straddle-mount platform. Optional ROPS with isolated platform (IOOS). Optional cab. |
| Transmissions: | 9-speed collar shift |
| 9-speed partially synchronized | |
| 12-speed power shuttle | |
Capacity | |
| Fuel: | 22 gal 83.3 L (ROPS early) |
| 25 gal 94.6 L (ROPS late) | |
| 27 gal 102.2 L (IOOS/cab small) | |
| 29.5 gal 111.7 L (IOOS/cab large) | |
| Hydraulic system: | 10 gal 37.9 L |
| 11.5 gal 43.5 L (PowrReverser) | |
| Front axle: | 6.6 qts 6.2 L |
| Front hubs: | 0.74 qts 0.7 L (each) |
| Front diff.: | 5.2 qts 4.9 L |
Hydraulics | |
| Type: | open center |
| Capacity: | 10 gal 37.9 L |
| 11.5 gal 43.5 L (PowrReverser) | |
| Pressure: | 2800 psi 193.1 bar |
| Valves: | 2 to 3 |
| Pump flow: | 15.9 gpm 60.2 lpm |
| Steering flow: | 6.6 gpm 25.0 lpm |
| Steering press.: | 1900 psi 131.0 bar |
Tractor hitch | |
| Rear Type: | II/I |
| Rear lift (at 24"/610mm): | 3,374 lbs 1530 kg |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Rear RPM: | 540 |
| 540/540E | |
| Engine RPM: | 540@2400 540E@1700 |
5520 Serial Numbers | |
| Location: | The tractor's serial number plate is on the right side of the frame, above the front axle. |
| 2002: | 250001 |
| 2003: | 350001 |
| 2004: | 450001 |
Electrical | |
| Ground: | negative |
| Charging system: | alternator |
| Charging amps: | 65 |
| Battery CCA: | 700 (early) |
| 950 (late) | |
| Battery volts: | 12 |
| Battery Group: | 31 |
Engine Detail | |
| John Deere 4045D | |
| turbocharged diesel | |
| 4-cylinder | |
| liquid-cooled | |
| Displacement: | 276 ci 4.5 L |
| Bore/Stroke: | 4.19x5.00 inches 106 x 127 mm |
| Power: | 89 hp 66.4 kW |
| Compression: | 17.0:1 |
| Rated RPM: | 2400 |
| Idle RPM: | 825-2625 |
| Operating RPM: | 1600-2400 |
| Torque: | 227.2 lb-ft 308.1 Nm |
| Torque RPM: | 1500 |
| Firing order: | 1-3-4-2 |
| Starter volts: | 12 |
| Coolant capacity: | 11.4 qts 10.8 L |
| Intake valve clearance: | 0.014 inches 0.356 mm |
| Exhaust valve clearance: | 0.018 inches 0.457 mm |
Dimensions | |
| ROPS Wheelbase: | 85.7 inches 217 cm |
| 2WD cab Wheelbase: | 85 inches 215 cm |
| 4WD cab Wheelbase: | 86 inches 218 cm |
| ROPS Length: | 151.5 inches 384 cm |
| 2WD cab Length: | 145.5 inches 369 cm |
| 4WD cab Length: | 148 inches 375 cm |
| ROPS Width: | 74.1 inches 188 cm |
| Cab Width: | 77.3 inches 196 cm |
| 2WD Ground clearance: | 18.8 inches 47 cm |
| 4WD Ground clearance: | 17.7 inches 44 cm |
