Deere 5115ML
Contents:
Production | |
| Manufacturer: | John Deere |
| Type: | Orchard/Vineyard tractor |
John Deere 5115ML Power | |
| Engine (gross): | 115 hp 85.8 kW |
| PTO (claimed): | 100 hp 74.6 kW |
Mechanical | |
| Chassis: | 4x4 MFWD 4WD |
| Steering: | power |
| Brakes: | hydraulic wet disc |
| Cab: | Two-post foldable ROPS. |
| Transmission: | 16-speed |
Capacity | |
| Fuel: | 40 gal 151.4 L |
| Hydraulic system: | 14 gal 53.0 L |
Hydraulics | |
| Type: | open center |
| Capacity: | 14 gal 53.0 L |
| Pressure: | 2900 psi 200.0 bar |
| Valves: | 3 to 5 |
| SCV flow: | 18.4 gpm 69.6 lpm |
| Total flow: | 24.7 gpm 93.5 lpm |
| Steering flow: | 6.3 gpm 23.8 lpm |
| Steering press.: | 1950 psi 134.5 bar |
Tractor hitch | |
| Rear Type: | II |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Clutch: | electro-hydraulic |
| Rear RPM: | 540/540E |
| Engine RPM: | 540@2100 540E@1645 |
5115ML Serial Numbers | |
| Location: | Serial number plate on the right side of the tractor frame, above the front axle. |
Electrical | |
| Ground: | negative |
| Charging system: | alternator |
| Charging amps: | 90 |
| 120*Available as a field-installed option. | |
| Battery CCA: | 950 |
| Battery volts: | 12 |
Engine Detail | |
| John Deere | |
| turbocharged aftercooled diesel | |
| 4-cylinder | |
| liquid-cooled inline | |
| Displacement: | 276 ci 4.5 L |
| Bore/Stroke: | 4.19x5.00 inches 106 x 127 mm |
| Emission control: | Interim Tier IV |
| Rated Power (EC 97/98): | 115 hp 85.8 kW |
| Rated RPM: | 2200 |
| Idle RPM: | 900-2300 |
| Starter: | electric |
| Starter volts: | 12 |
| Oil capacity: | 13.6 qts 12.9 L |
| Coolant capacity: | 20 qts 18.9 L |
Transmission | |
| Transmission: | PowrReverser |
| Gears: | 16 forward and reverse |
| Four gears (1-4) in four ranges (A-D) with left-hand reverser lever. Gear shifts and ranges C/D shifts are synchronized. Power shuttle shifting. | |
Dimensions | |
| Wheelbase: | 90.6 inches 230 cm |
| Width: | 84 inches 213 cm |
| Height (ROPS): | 89.3 inches 226 cm |
| Shiping weight: | 7950 lbs 3606 kg |
| Clearance (front axle): | 14 inches 35 cm |
