Deere 3030
Type: Row-crop Tractors
Contents:
Production | |
| Manufacturer: | John Deere |
| Type: | Row-Crop tractor |
| Factory: | Mannheim, Baden-Württemberg, Germany |
Variants | |
| 3030LS: | 12-speed |
John Deere 3030 Power | |
| Engine (gross): | 93.8 hp 69.9 kW |
| Engine (net): | 84.5 hp 63.0 kW |
| PTO (claimed): | 76.4 hp 57.0 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| 4x4 MFWD 4WD | |
| Final drives: | planetary |
| Differential lock: | mechanical rear |
| Steering: | power |
| Brakes: | wet disc |
| Cab: | Four-post ROPS. Cab available. |
| Transmission: | 12-speed |
Capacity | |
| Fuel: | 28 gal 106.0 L |
| Hydraulic system: | 15 gal 56.8 L |
Hydraulics | |
| Type: | closed center |
| Capacity: | 15 gal 56.8 L |
| Pressure: | 2248 psi 155.0 bar |
| Pump flow: | 12.4 gpm 46.9 lpm |
Tractor hitch | |
| Rear Type: | II |
| Control: | position and draft control |
| Rear lift: | 7452 lbs 3380 kg |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Rear RPM: | 540/1000 |
| Engine RPM: | 540@2170 1000@2170 |
3030 Serial Numbers | |
| Location: | Serial number plate on the right side of the Deere 3030 tractor frame, above the front axle. |
Electrical | |
| Ground: | negative |
| Charging system: | alternator |
| Charging amps: | 28 |
| Batteries: | 2 |
| Battery volts: | 12 |
| Battery AH: | 55 |
Dimensions | |
| Wheelbase: | 97 inches 246 cm |
| Length: | 157.5 inches 400 cm |
| Width: | 80.3 inches 203 cm *Minimum width. |
| Height (ROPS): | 105.7 inches 268 cm |
| Height (cab): | 107.5 inches 273 cm |
