Deere 2550
Type: Utility Tractors
Contents:
Production | |
| Manufacturer: | John Deere |
| Type: | Utility tractor |
| Factory: | Mannheim, Baden-Württemberg, Germany |
| Original price: | $22,000 (1986 ) |
John Deere 2550 Power | |
| PTO (claimed): | 65 hp 48.5 kW |
| Drawbar (tested): | 55.38 hp 41.3 kW |
| PTO (tested): | 65.94 hp 49.2 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| 4x4 MFWD 4WD | |
| Differential lock: | rear standard |
| Steering: | hydrostatic power |
| Brakes: | differential hydraulic wet disc |
| Cab: | Two-post ROPS. Canopy available. Sound-Gard cab optional with available heat and air-conditioning. |
| Transmissions: | 8-speed partially synchronized |
| 16-speed partial power shift | |
| 8-speed power shuttle | |
| 12-speed partially synchronized | |
Hydraulics | |
| Type: | closed center |
| Pressure: | 2300 psi 158.6 bar |
| Rear valves: | 1 or 2 |
| Pump flow: | 13 gpm 49.2 lpm |
Tractor hitch | |
| Rear Type: | II/I |
| Control: | load and depth control |
| Rear lift: | 2,735 lbs 1240 kg |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| live (with reverser) | |
| Rear RPM: | 540 |
| 540/1000*Optional | |
| Engine RPM: | 540@2382 |
2550 Serial Numbers | |
| Location: | Right side of main tractor frame, above front axle. |
Electrical | |
| Ground: | negative |
| Charging system: | alternator |
| Charging amps: | 33 |
| 55 | |
| Battery volts: | 12 |
Engine Detail | |
| John Deere | |
| diesel | |
| 4-cylinder | |
| liquid-cooled | |
| Displacement: | 239 ci 3.9 L |
| Bore/Stroke: | 4.19x4.33 inches 106 x 110 mm |
| Air cleaner: | dual paper elements |
| Compression: | 17.4:1 |
| Rated RPM: | 2500 |
| Operating RPM: | 1500-2500 |
| Starter volts: | 12 |
| Coolant capacity: | 13.6 qts 12.9 L |
Dimensions | |
| 2WD Wheelbase: | 89.2 inches 226 cm |
| 4WD Wheelbase: | 90 inches 228 cm |
| 2WD Length: | 133.4 inches 338 cm |
| Height (steering wheel): | 61.4 inches 155 cm |
| Height (cab): | 101.4 inches 257 cm |
| 2WD Clearance (front axle): | 24.8 inches 62 cm |
| 4WD Clearance (front axle): | 17.5 inches 44 cm |
