Cockshutt 50
Type: Row-crop Tractors
Contents:
Production | |
| Manufacturer: | Cockshutt |
| Type: | Row-Crop tractor |
| Factory: | Brantford, Ontario, Canada |
| Total built: | 3,974 |
| Original price: | $4,100 (1957) |
Cockshutt 50 Power | |
| Drawbar (claimed): | 39 hp 29.1 kW |
| Belt (claimed): | 49 hp 36.5 kW |
| Plows: | 4-5 |
| Drawbar (tested): | 51.59 hp 38.5 kW |
| Belt (tested): | 55.56 hp 41.4 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| Brakes: | independent mechanical disc |
| Cab: | Open operator station. |
| Transmission: | 6-speed unsynchronized gear |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Rear RPM: | 540 |
50 Serial Numbers | |
| Location: | Serial number stamped into the top of the Cockshutt 50 tractor frame on the left side. |
| 1953: | 101 |
| 1954: | 1750 |
| 1955: | 10001 |
| 1956: | 20001 |
| 1957: | 30001 |
| 1958: | 40001 |
| Final: | 40257 |
Engine Detail | |
| Buda | |
| gasoline | |
| 6-cylinder | |
| liquid-cooled vertical I-head | |
| Displacement: | 273 ci 4.5 L |
| Bore/Stroke: | 3.75x4.125 inches 95 x 105 mm |
| Compression: | 6.6:1 |
| Rated RPM: | 1650 |
Transmission | |
| Type: | unsynchronized gear |
| Gears: | 6 forward and 2 reverse |
| Clutch: | dry disc |
Dimensions | |
| Wheelbase: | 86.5 inches 219 cm |
| Length: | 132 inches 335 cm |
| Height: | 79.5 inches 201 cm |
