Claas Arion 540

Production: 2007 - 2011

Production
Manufacturer:	Claas
Type:	Row-Crop tractor

Claas Arion 540 Power
Engine:	135 hp 100.7 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Trailer brakes:	air (optional)
Cab:	Cab standard with air-conditioning.
Transmission:	24-speed partial power shift with power shuttle

Hydraulics
Type:	open center
load sensing (optional)
Pressure:	2901 psi 200.0 bar
Valves:	2 to 6
Total flow:	15.9 gpm 60.2 lpm
29.1 gpm 110.1 lpm (optional)

Power Take-off (PTO)
Rear RPM:	540/1000
540/540E/1000/1000E (optional)

Engine Detail
DPS
turbocharged intercooled diesel
4-cylinder 16-valve
liquid-cooled
Displacement:	276.1 ci 4.5 L
Emissions:	Tier 3
Power:	135 hp 100.7 kW
Rated RPM:	2200
Torque:	425.6 lb-ft 577.1 Nm
Torque RPM:	1650
Oil change:	500 h

Transmission
Transmission:	Hexashift
Type:	partial power shift with power shuttle
Gears:	24 forward and reverse

Dimensions
Wheelbase:	100.8 inches 256 cm
Length:	192.5 inches 488 cm
Height (cab):	116.6 inches 296 cm
Ground clearance:	19.2 inches 48 cm
