Claas Arion 460
Type: Row-crop Tractors
Contents:
Production | |
| Manufacturer: | Claas |
| Type: | Row-Crop tractor |
Claas Arion 460 Power | |
| Engine (gross): | 139 hp 103.7 kW |
| Engine (max): | 140 hp 104.4 kW |
Mechanical | |
| Chassis: | 4x4 MFWD 4WD |
| Differential lock: | electro-hydraulic |
| Cab: | Cab standard. Air-conditioning optional. |
| Transmission: | 16-speed four-speed power shift |
Hydraulics | |
| Type: | open center |
| closed center load-sensing*Optional | |
| Pressure: | 2756 psi 190.0 bar |
| Valves: | 2 to 4 |
| Pump flow: | 15.85 gpm 60.0 lpm |
| 25.9 gpm 98.0 lpm *Optional, open center | |
| 29.1 gpm 110.1 lpm *Optional, load sensing | |
Tractor hitch | |
| Rear Type: | III |
| Rear lift (at ends): | 9259 lbs 4199 kg |
| Front lift: | 6173 lbs 2800 kg |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Clutch: | wet disc |
| Rear RPM: | 540/540E |
| 540/540E/1000*Optional | |
| Front PTO: | independent*Optional |
| Front RPM: | 1000 |
Electrical | |
| Ground: | negative |
| Charging system: | alternator |
| Battery volts: | 12 |
Engine Detail | |
| FPT | |
| turbocharged intercooled diesel | |
| 4-cylinder 16-valve | |
| liquid-cooled | |
| Displacement: | 274.6 ci 4.5 L |
| Emissions: | Stage IV |
| Emission control: | diesel oxidation catalyist (DOC) with selective catalytic reduction (SCR) |
| Rated Power (EC 97/98): | 139 hp 103.7 kW |
| Rated Power (ECE R120): | 135 hp 100.7 kW |
| Maximum Power (ECE R120): | 140 hp 104.4 kW |
| Fuel system: | common rail |
| Rated RPM: | 2200 |
| Torque: | 420.4 lb-ft 570.1 Nm |
| Torque RPM: | 1400 |
| Starter: | electric |
| Starter volts: | 12 |
| Oil change: | 600 h |
Transmission | |
| Transmission: | Quadrishift |
| Type: | four-speed power shift |
| Gears: | 16 forward and reverse |
| Four power shift gears (1-4) in four hydraulically shifted ranges (A-D) with power shuttle. Optional Quadractiv automatic shifting. | |
Dimensions | |
| Wheelbase: | 99.4 inches 252 cm |
| Length: | 175 inches 444 cm |
| Height (cab): | 108.9 inches 276 cm |
| Weight: | 11240 lbs 5098 kg |
| Max weight: | 18740 lbs 8500 kg |
| Clearance (front axle): | 19.9 inches 50 cm |
| Clearance (rear axle): | 19.3 inches 49 cm |
| Front axle: | Proactive suspension |
| Front tread: | 72.4 to inches 183 to 0 cm |
