Chamberlain Canelander

Production: 1959 - 1973

Production
Manufacturer:	Chamberlain
Type:	High-Clearance tractor
Factory:	Welshpool, Australia

Chamberlain Canelander Power
Engine:	62 hp 46.2 kW
Drawbar (claimed):	48 hp 35.8 kW
PTO (claimed):	55 hp 41.0 kW

Mechanical
Chassis:	4x2 2WD
Steering:	manual
Brakes:	mechanical expanding
Cab:	Open operator station.
Transmissions:	9-speed gear
9-speed

Capacity
Fuel:	19.5 gal 73.8 L
Hydraulic system:	2.4 gal 9.1 L

Hydraulics
Type:	open center
Capacity:	2.4 gal 9.1 L
Pressure:	1750 psi 120.7 bar
Pump flow:	9.8 gpm 37.1 lpm

Tractor hitch
Rear Type:	II
Rear lift (at ends):	3500 lbs 1587 kg

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	540 (1.375)
Engine RPM:	540@1600

Engine Detail
Perkins 4-270D
diesel
4-cylinder
liquid-cooled
Displacement:	270 ci 4.4 L
Bore/Stroke:	4.25x4.75 inches 108 x 121 mm
Power:	62 hp 46.2 kW
Pre-heating:	thermostart
Compression:	16:1
Rated RPM:	2000
Starter volts:	12

Dimensions
Wheelbase:	92 inches 233 cm
Length:	149 inches 378 cm
Width:	79 inches 200 cm
Height (steering wheel):	75.5 inches 191 cm
Operating weight:	7350 lbs 3333 kg
Ballasted weight:	9310 lbs 4223 kg
Ground clearance:	26 inches 66 cm
Front tread:	56 to 80 inches 142 to 203 cm
Rear tread:	54 to 78.5 inches 137 to 199 cm
