Chamberlain Countryman
Type: Standard-tread Tractors
Contents:
Production | |
| Manufacturer: | Chamberlain |
| Type: | Standard-tread tractor |
| Factory: | Welshpool, Australia |
Variants | |
| MkI: | 1958-1959 |
| MkII: | 1960 |
| MkIII: | 1961-1962 |
Chamberlain Countryman Power | |
| Engine: | 76 hp 56.7 kW |
| Drawbar (claimed): | 60 hp 44.7 kW |
| Belt (claimed): | 67 hp 50.0 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| Brakes: | internal expanding |
| Cab: | Open operator station. |
| Transmission: | 9-speed gear |
Hydraulics | |
| Total flow: | 7.7 gpm 29.1 lpm (MkIII) |
Power Take-off (PTO) | |
| Rear PTO: | indepenent |
| Rear RPM: | 540 (1.375) |
| Engine RPM: | 540@1600 |
Countryman Serial Numbers | |
| 1958: | 101 |
| 1959: | 1158 |
| 1960: | 1344 |
| 1961: | 1407 (Mk 3) |
| 1961: | 1609 (Mk 3) |
| 1962: | 1828 (Mk 3) |
| Final: | 2003 (Mk 3) |
Engine Detail | |
| Meadows 4DC330 | |
| diesel | |
| 4-cylinder | |
| liquid-cooled | |
| Displacement: | 332 ci 5.4 L |
| Bore/Stroke: | 4.724x4.724 inches 120 x 120 mm |
| Power: | 76 hp 56.7 kW |
| Compression: | 16:1 |
| Rated RPM: | 1800 |
| Starter volts: | 12 |
Transmission | |
| Type: | gear |
| Gears: | 9 forward and 3 reverse |
| Clutch: | 355.6mm dry disc |
| Three gears, plus reverse, in three ranges. | |
Dimensions | |
| Wheelbase: | 86.5 inches 219 cm |
| Length: | 146 inches 370 cm |
| Width: | 88 inches 223 cm |
| Height (steering wheel): | 70.5 inches 179 cm |
| Weight: | 9000 lbs 4082 kg |
| Ground clearance: | 18 inches 45 cm |
