Challenger MT875C

Production: 2009 - 2013

Production
Manufacturer:	Challenger (a part of AGCO)
Type:	Agricultural Crawler tractor
Factory:	Jackson, Minnesota, USA
Original price:	$473,854 (2013 )

Challenger MT875C Power
Engine (gross):	585 hp 436.2 kW
PTO (claimed):	425 hp 316.9 kW
Drawbar (tested):	441.14 hp 329.0 kW
PTO (tested):	586.45 hp 437.3 kW

Mechanical
Chassis:	crawler
Steering:	speed sensitive differential
Brakes:	hydraulic wet discs
Trailer brakes:	hydraulic*Optional
Cab:	Cab standard with air-conditioning.
Transmission:	16-speed full power shift

Hydraulics
Type:	closed center pressure-flow compensated
Pressure:	2900 psi 200.0 bar
Valves:	4 to 6
SCV flow:	36 gpm 136.3 lpm
Total flow:	43.5 gpm 164.6 lpm
59 gpm 223.3 lpm *Optional

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	1000 (1.75)

Electrical
Ground:	negative
Charging system:	alternator
Charging amps:	185
Batteries:	4
Battery CCA:	1000
Battery volts:	12

Engine Detail
Caterpillar C18 ACERT
turbocharged aftercooled diesel
6-cylinder 24-valve
liquid-cooled
Displacement:	1,106 ci 18.1 L
Bore/Stroke:	5.71x7.2 inches 145 x 183 mm
Emissions:	Tier III
Power (gross):	585 hp 436.2 kW
Maximum Power:	631 hp 470.5 kW
Fuel system:	mechanical electric injector unit (MEUI)
Rated RPM:	2100
Starter:	electric
Starter volts:	12

Transmission
Transmission:	Caterpillar Powershift
Type:	full power shift
Gears:	16 forward and 4 reverse
Clutch:	hydraulic wet discs

Dimensions
Wheelbase:	118 inches 299 cm
Length:	270 inches 685 cm
Width:	141.8 inches 360 cm
Height (cab):	138.1 inches 350 cm
Shiping weight:	42,200 lbs 19141 kg
Max weight:	50,000 lbs 22680 kg
Clearance (drawbar):	14.4 inches 36 cm
Gauge:	90 to 128 inches 228 to 325 cm
