Caterpillar 2-Ton
Contents:
Production | |
| Manufacturer: | Caterpillar |
| Type: | Agricultural Crawler tractor |
| Factories: | Stockton, California, USA |
| Peoria, Illinois, USA | |
| Total built: | 1,350 (Stockton) |
| 8,989 (Peoria) | |
| Original price: | $1,850 (1927 ) |
| The Caterpillar 2-Ton was a continuation of the Holt 2-Ton, which was the new name for the Holt T-35. | |
Caterpillar 2-Ton Power | |
| Drawbar (claimed): | 15 hp 11.2 kW |
| Belt (claimed): | 25 hp 18.6 kW |
| Drawbar (tested): | 18.2 hp 13.6 kW |
| Belt (tested): | 25.5 hp 19.0 kW |
Mechanical | |
| Chassis: | crawler |
| Cab: | Open operator station. |
| Transmission: | 3-speed gear |
2-Ton Serial Numbers | |
| 1921: | 25003 (Holt CA) |
| 1922: | 25056 (Holt CA) |
| 1923: | 25577 (Holt CA) |
| 1924: | 26313 (Holt CA) |
| 1924: | 70001 (Holt IL) |
| 1925: | 70424 (Holt IL) |
| 1925: | 70817 (Cat IL) |
| 1926: | 71529 (Cat IL) |
| 1927: | 73146 (Cat IL) |
| 1928: | 75286 (Cat IL) |
| Final: | 78989 (Cat IL) |
Engine Detail | |
| Caterpillar | |
| gasoline | |
| 4-cylinder 8-valve | |
| liquid-cooled | |
| Displacement: | 251 ci 4.1 L |
| Bore/Stroke: | 4.00x5.00 inches 102 x 127 mm |
| Rated RPM: | 1000 |
| Starter type: | hand crank |
Transmission | |
| Type: | gear |
| Gears: | 3 forward and 1 reverse |
Dimensions | |
| Operating weight: | 4,040 lbs 1832 kg |
