ATC Terratrac GT-30

Production: 1951 - 1954

Production
Manufacturer:	ATC
Type:	Agricultural Crawler tractor
Factory:	Churubusco, Indiana, USA

ATC GT-30 Power
Drawbar (tested):	25.16 hp 18.8 kW
Belt (tested):	30.41 hp 22.7 kW

Mechanical
Chassis:	crawler
Steering:	manual
Brakes:	mechanical contracting band
Cab:	Open operator station.
Transmission:	3-speed unsycnchronized gear

GT-30 Serial Numbers
1951:	10001
1952:	10488
1953:	11197
1954:	11359
Final:	11463

Engine Detail
Continental
gasoline
4-cylinder
liquid-cooled
Displacement:	139.6 ci 2.3 L
Bore/Stroke:	3.1875x4.375 inches 81 x 111 mm
Compression:	6.5:1
Rated RPM:	1850
Starter volts:	6
Coolant capacity:	12 qts 11.4 L

Transmission
Type:	unsycnchronized gear
Gears:	3 forward and 1 reverse
Clutch:	dry disc

Dimensions
Length:	96 inches 243 cm
Height:	51 inches 129 cm
Weight:	4471 lbs 2028 kg
