Ag King AK3540

Production
Distributor:	Ag King
Manufacturer:	Jinma
Factory:	Yancheng City, China

Ag King AK3540 Power
Engine:	35 hp 26.1 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Steering:	hydrostatic power
Transmission:	6-speed

Capacity
Fuel:	8 gal 30.3 L
Hydraulic system:	2.2 gal 8.3 L

Hydraulics
Capacity:	2.2 gal 8.3 L
Steering flow:	12 gpm 45.4 lpm

Tractor hitch
Rear Type:	I
Rear lift:	1,100 lbs 498 kg

Power Take-off (PTO)
Rear PTO:	transmission
Rear RPM:	540/720

Engine Detail
485
diesel
4-cylinder
liquid-cooled
Displacement:	82.75 ci 1.4 L
Power:	35 hp 26.1 kW
Rated RPM:	2400
Oil capacity:	6.4 qts 6.1 L
Coolant capacity:	8 qts 7.6 L

Transmission
Gears:	6 forward and 2 reverse
Oil capacity:	19 qts 18.0 L

Dimensions
Wheelbase:	66 inches 167 cm
Length:	121 inches 307 cm
Width:	54 inches 137 cm
Height:	85 inches 215 cm
Weight:	3895 lbs 1766 kg
Ground clearance:	11.6 inches 29 cm
