Ag King AK2040

Production
Distributor:	Ag King
Manufacturer:	Jinma
Factory:	Yancheng City, China
The Ag King 2040 is similar to the Jinma JM-224

Ag King AK2040 Power
Engine:	20 hp 14.9 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Steering:	hydrostatic power
Transmission:	12-speed

Capacity
Fuel:	5.5 gal 20.8 L
Hydraulic system:	2.4 gal 9.1 L

Hydraulics
Capacity:	2.4 gal 9.1 L
Steering flow:	8.62 gpm 32.6 lpm

Tractor hitch
Rear Type:	I
Rear lift:	810 lbs 367 kg

Power Take-off (PTO)
Rear PTO:	transmission
Rear RPM:	540/1000

Engine Detail
380
diesel
3-cylinder
liquid-cooled
Displacement:	82.75 ci 1.4 L
Power:	20 hp 14.9 kW
Rated RPM:	2400
Oil capacity:	3.7 qts 3.5 L
Coolant capacity:	10.4 qts 9.8 L

Transmission
Gears:	12 forward and 4 reverse
Oil capacity:	13 qts 12.3 L

Dimensions
Wheelbase:	65 inches 165 cm
Length:	120 inches 304 cm
Width:	54 inches 137 cm
Height:	85 inches 215 cm
Weight:	2470 lbs 1120 kg
Ground clearance:	11.6 inches 29 cm
