Yanmar Ex450

Production: 2012
Type: Compact Utility Tractors

Contents:

PDF

Production

Manufacturer:Yanmar
Type:Compact Utility tractor
Original price:$21,299 (2009)

Yanmar Ex450 Power

Engine (gross):45 hp 33.6 kW
PTO (claimed):37.5 hp 28.0 kW

Mechanical

Chassis:4x4 MFWD 4WD
Steering:hydraulic power
Brakes:wet disc
Cab:Two-post ROPS.
Transmission:9-speed synchronized shuttle

Capacity

Fuel:11.3 gal 42.8 L
Front axle:8 qts 7.6 L

Hydraulics

Type:open center
Valves:2 or 3
Pump flow:8.2 gpm 31.0 lpm
Total flow:12.7 gpm 48.1 lpm
Steering flow:4.5 gpm 17.0 lpm

Tractor hitch

Rear Type:1
Control:position control
Rear lift (at 24"/610mm):2,464 lbs 1117 kg

Power Take-off (PTO)

Rear PTO:live
Clutch:dry dual stage
Rear RPM:540

Electrical

Ground:negative
Battery volts:12

Engine Detail

Yanmar
diesel
4-cylinder
liquid-cooled
Displacement:133.6 ci 2.2 L
Bore/Stroke:3.465x3.543 inches 88 x 90 mm
Power (gross):45 hp 33.6 kW
Fuel system:direct injection
Air cleaner:dual dry elements
Rated RPM:2700
Starter:electric
Starter volts:12
Oil capacity:5.6 qts 5.3 L
Coolant capacity:4.7 qts 4.4 L

Transmission

Type:synchronized shuttle
Gears:9 forward and reverse
Clutch:dual stage dry
Oil capacity:28 qts 26.5 L

Dimensions

Wheelbase:72 inches 182 cm
Length:127 inches 322 cm
Width:71.89 inches 182 cm
Operating weight:3,499 lbs 1587 kg
Ground clearance:13.4 inches 34 cm
