Zetor 7711
Contents:
Production | |
| Manufacturer: | Zetor |
| Factory: | Brno, Czechoslovakia |
| Original price: | $16500 (1992) |
Variants | |
| 2WD | |
| 4WD |
Zetor 7711 Power | |
| Engine: | 81 hp 60.4 kW |
| Drawbar (claimed): | 58 hp 43.3 kW |
| PTO (claimed): | 66 hp 49.2 kW |
| 75 hp 55.9 kW (turbo) | |
| Drawbar (tested): | 55.87 hp 41.7 kW |
| PTO (tested): | 65.74 hp 49.0 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| Steering: | power assist |
| Brakes: | differential hydraulic dry disc |
| Transmission: | 10-speed partially synchronized |
Hydraulics | |
| Type: | open |
| Pressure: | 2,321 psi 160.0 bar |
| Valves: | 2 |
| Total flow: | 7.9 gpm 29.9 lpm |
Tractor hitch | |
| Rear Type: | II/I |
| Rear lift: | 5300 lbs 2404 kg |
| Front Hitch: | II (optional) |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Rear RPM: | 540/1000 |
| Front RPM: | 1000 |
Electrical | |
| Charging system: | alternator |
| Charging amps: | 55 |
| Battery volts: | 12 |
Engine Detail | |
| Zetor 7701 | |
| diesel | |
| 4-cylinder | |
| liquid-cooled | |
| Displacement: | 239.3 ci 3.9 L |
| Bore/Stroke: | 4.02x4.72 inches 102 x 120 mm |
| Power: | 73 hp 54.4 kW |
| Air cleaner: | oil bath with pre-cleaner |
| Compression: | 17:1 |
| Rated RPM: | 2200 |
| Starter volts: | 12 |
| Coolant capacity: | 14.5 qts 13.7 L |
Transmission | |
| Type: | partially synchronized |
| Gears: | 10 forward and 2 reverse |
| Five gears, plus reverse, in high and low ranges. Fourth and fifth gears are synchronized. | |
Dimensions | |
| Wheelbase: | 87.5 inches 222 cm |
| Length: | 149.6 inches 379 cm |
| Width: | 72.4 inches 183 cm |
| Height (cab): | 104.3 inches 264 cm |
| Height (exhaust): | 106.7 inches 271 cm |
| Weight: | 6900 lbs 3129 kg |
| Ground clearance: | 20.3 inches 51 cm |
