Zetor 7245
Contents:
Production | |
| Manufacturer: | Zetor |
| Factory: | Brno, Czechoslovakia |
| Original price: | $17,000 (1989 ) |
Variants | |
| 2WD | |
| 4WD |
Zetor 7245 Power | |
| Engine: | 64.6 hp 48.2 kW |
| Drawbar (claimed): | 53 hp 39.5 kW |
| PTO (claimed): | 58 hp 43.3 kW |
| Drawbar (tested): | 51.28 hp 38.2 kW |
| PTO (tested): | 58.28 hp 43.5 kW |
Mechanical | |
| Chassis: | 4x4 MFWD 4WD |
| Steering: | power |
| Brakes: | hydraulic drum |
| Transmission: | 10-speed sliding gear |
Capacity | |
| Fuel: | 18.5 gal 70.0 L |
| Hydraulic system: | 26.5 gal 100.3 L |
Hydraulics | |
| Type: | open center |
| Capacity: | 26.5 gal 100.3 L |
| Valves: | 2 |
| Pump flow: | 28 gpm 106.0 lpm |
Tractor hitch | |
| Rear Type: | II/I |
| Rear lift: | 5300 lbs 2404 kg |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Rear RPM: | 540/1000 |
Electrical | |
| Ground: | negative |
| Battery volts: | 12 |
Engine Detail | |
| Zetor | |
| diesel | |
| 4-cylinder | |
| liquid-cooled | |
| Displacement: | 219.4 ci 3.6 L |
| Power: | 64.6 hp 48.2 kW |
| Starter volts: | 12 |
| Coolant capacity: | 14.5 qts 13.7 L |
Transmission | |
| Type: | sliding gear |
| Gears: | 10 forward and 2 reverse |
| Clutch: | dry disc |
| Five gears, plus reverse, in two ranges. | |
Dimensions | |
| Wheelbase: | 87.8 inches 223 cm |
| Weight: | 7400 lbs 3356 kg |
