XTZ-17022

Production
Manufacturer:	XTZ
Type:	Four-wheel Drive (4WD) tractor
Factory:	Kharkiv, Ukraine

XTZ XTZ-17022 Power
Engine:	180 hp 134.2 kW

Mechanical
Chassis:	4x4 articulated 4WD
Final drives:	planetary
Steering:	articulated power
Brakes:	pneumatic drum
Cab:	Cab standard, air-conditioning available.
Transmission:	12-speed

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	540/1000

Engine Detail
Deutz BF6M1013E
diesel
6-cylinder
liquid-cooled inline
Displacement:	435 ci 7.1 L
Bore/Stroke:	4.252x5.512 inches 108 x 140 mm
Power:	180 hp 134.2 kW
Rated RPM:	2200
Starter type:	electric

Transmission
Gears:	12 forward and 4 reverse
Clutch:	dry disc
Four gears in three ranges, plus reverse range.

Dimensions
Wheelbase:	112.6 inches 286 cm
Length:	255.9 inches 649 cm
Width:	96.9 inches 246 cm
Height (exhaust):	132.3 inches 336 cm
Weight:	19180 lbs 8700 kg
Ground clearance:	17.7 inches 44 cm
Front tread:	73.2 inches 185 cm
Rear tread:	73.2 inches 185 cm
