White Field Boss 37
Type: Compact Utility Tractors
Contents:
Production | |
| Distributor: | White |
| Manufacturer: | Iseki |
| Type: | Compact Utility tractor |
| Original price: | $11,000 (1988) |
Variants | |
| Iseki TE4370: | similar model |
White Field Boss 37 Power | |
| Engine: | 37 hp 27.6 kW |
| PTO (claimed): | 30 hp 22.4 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| 4x4 MFWD 4WD (optional) | |
| Final drives: | helical gear |
| Steering: | power |
| Brakes: | mechanical wet disc |
| Cab: | Two-post ROPS. Optional canopy. |
| Transmission: | 18-speed |
Hydraulics | |
| Type: | open center |
| Pressure: | 2135 psi 147.2 bar |
| Valves: | 1 or 2 |
| Pump flow: | 7.7 gpm 29.1 lpm |
Tractor hitch | |
| Rear Type: | 1 |
| Control: | position and draft control |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Clutch: | electric-hydraulic wet discs |
| Rear RPM: | 540 |
| Engine RPM: | 540@2232 |
Field Boss 37 Serial Numbers | |
| Location: | Frame, front-left |
| 1986: | 00083 (2WD) |
| 1987: | 00121 (2WD) |
| 1988: | 00221 (2WD) |
| 1986: | 0679 (4WD) |
| 1987: | 00713 (4WD) |
| 1988: | 01025 (4WD) |
Electrical | |
| Ground: | negative |
| Charging system: | alternator |
| Charging amps: | 35 |
| Battery CCA: | 531 |
| Battery volts: | 12 |
Engine Detail | |
| Isuzu | |
| diesel | |
| 4-cylinder | |
| liquid-cooled | |
| Displacement: | 110.8 ci 1.8 L |
| Bore/Stroke: | 3.31x3.23 inches 84 x 82 mm |
| Power: | 37 hp 27.6 kW |
| Air cleaner: | dry element |
| Pre-heating: | glow plugs |
| Compression: | 21:1 |
| Rated RPM: | 2600 |
| Firing order: | 1-3-4-2 |
| Starter volts: | 12 |
| Oil capacity: | 7.44 qts 7.0 L |
Transmission | |
| Gears: | 18 forward and 6 reverse |
| Clutch: | dry disc |
Dimensions | |
| Wheelbase: | 70.9 inches 180 cm |
| Length: | 126.4 inches 321 cm |
| Width: | 71.5 inches 181 cm |
| Height (ROPS): | 84 inches 213 cm |
| Height (exhaust): | 78.8 inches 200 cm |
| 2WD, 3,153 4WD} Shiping weight: | 2,921 lbs 1324 kg |
| Ground clearance: | 13 inches 33 cm |
| 2WD Front tread: | 45.3 to 61 inches 115 to 154 cm |
| 4WD Front tread: | 47.6 inches 120 cm |
| Rear tread: | 44.9 to 59.1 inches 114 to 150 cm |
