Volvo T350 Boxer

Production: 1959 - 1967

Production
Manufacturer:	Volvo
Total built:	28439

Volvo T350 Power
Engine:	56 hp 41.8 kW

Mechanical
Chassis:	4x2 2WD
Steering:	manual
Cab:	Open operator station.
Transmission:	10-speed gear

Power Take-off (PTO)
Rear RPM:	540 (1.375)

Engine Detail
Bolinder TR 1113
diesel
3-cylinder
liquid-cooled
Displacement:	230.7 ci 3.8 L
Bore/Stroke:	4.37x5.12 inches 111 x 130 mm
Power:	56 hp 41.8 kW
Compression:	16.5:1
Rated RPM:	1800
Starter volts:	12
Oil capacity:	11.1 qts 10.5 L
Coolant capacity:	14.8 qts 14.0 L

Transmission
Type:	gear
Gears:	10 forward and 2 reverse
Oil capacity:	56 qts 53.0 L

Dimensions
Wheelbase:	90.8 inches 230 cm
Length:	140.6 inches 357 cm
Width:	69.7 inches 177 cm
Height (hood):	59.8 inches 151 cm
Height (exhaust):	93.5 inches 237 cm
Weight:	6327 lbs 2869 kg
Ground clearance:	19.1 inches 48 cm
Front tread:	52.4 to 56.3 inches 133 to 143 cm
Rear tread:	50.4 to 67.3 inches 128 to 170 cm
