Valpadana 1325

Production
Manufacturer:	Valpadana
Factory:	San Martino, Italy

Valpadana 1325 Power
Engine:	20.5 hp 15.3 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Steering:	power
Brakes:	disc

Hydraulics
Pressure:	1740 psi 120.0 bar
Valves:	1 standard
3 optional
Total flow:	3.2 gpm 12.1 lpm

Tractor hitch
Rear Type:	I
Rear lift:	1,168 lbs 529 kg

Power Take-off (PTO)
Rear RPM:	540

Engine Detail
403C-07
diesel
3-cylinder
liquid-cooled
Displacement:	46.5 ci 0.8 L
Bore/Stroke:	2.638x2.835 inches 67 x 72 mm
Power:	20.5 hp 15.3 kW
Air cleaner:	dry
Rated RPM:	3600
Torque:	36.9 lb-ft 50.0 Nm
Torque RPM:	2400

Transmission
Transmission:	Hydrostatic
Gears:	infinite 2-range forward and reverse

Dimensions
Wheelbase:	42.5 inches 107 cm
Length:	100.5 inches 255 cm
Width:	26.6 inches 67 cm
Height:	46.5 inches 118 cm
Weight:	1,246 lbs 565 kg
Ground clearance:	7.5 inches 19 cm
