Valpadana 3660

Production
Manufacturer:	Valpadana
Factory:	San Martino, Italy

Variants
F:	Narrow for orchards and vineyards
GE:	low-clearance

Valpadana 3660 Power
Engine:	58.8 hp 43.8 kW
PTO (claimed):	54 hp 40.3 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Brakes:	Wet disc
Cab:	cab with heat optional
Transmissions:	15-speed
30-speed
40-speed

Hydraulics
Valves:	2
Pump flow:	13.8 gpm 52.2 lpm
Total flow:	21.7 gpm 82.1 lpm
Steering flow:	7.9 gpm 29.9 lpm

Tractor hitch
Rear Type:	II
Rear lift:	5,732 lbs 2600 kg

Power Take-off (PTO)
Rear RPM:	540/750/ground
1000 optional

Engine Detail
1103C-33
diesel
3-cylinder
Displacement:	201.4 ci 3.3 L
Power:	58.8 hp 43.8 kW
Torque:	163.7 lb-ft 222.0 Nm

Dimensions
Wheelbase:	79.4 inches 201 cm
Length:	153.5 inches 389 cm
Width:	52 inches 132 cm (F)
56.5 inches 143 cm (GE)
Height:	88.6 inches 225 cm (F)
84.7 inches 215 cm (GE)
Weight:	6,184 lbs 2805 kg (F)
5,512 lbs 2500 kg (GE)
