Valmet 2005

Production: 1986 - 1987

Production
Manufacturer:	Valmet
Type:	Row-Crop tractor

Valmet 2005 Power
Engine:	140 hp 104.4 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Transmission:	16-speed two-speed power shift

Hydraulics
Pump flow:	11.36 gpm 43.0 lpm

Tractor hitch
Rear Type:	II
Rear lift:	11020 lbs 4998 kg

Power Take-off (PTO)
Rear PTO:	independent
Clutch:	hydraulic dry disc
Rear RPM:	540/1000

Electrical
Ground:	negative
Charging system:	alternator
Charging amps:	90
Charging volts:	14
Batteries:	2
Battery volts:	12

Engine Detail
Volvo TD60B
turbocharged diesel
6-cylinder
liquid-cooled
Displacement:	334.4 ci 5.5 L
Bore/Stroke:	3.875x4.724 inches 98 x 120 mm
Power:	140 hp 104.4 kW
Compression:	16:1
Rated RPM:	2300
Starter volts:	12

Transmission
Type:	two-speed power shift
Gears:	16 forward and 4 reverse
Clutch:	355.6mm dry disc
Four gears (1-4) plus reverse (R) in two ranges (low/high) with two-speed pushbutton power shift.

Dimensions
Wheelbase:	112 inches 284 cm
Length:	184.4 inches 468 cm
Height (cab):	119.1 inches 302 cm
Height (exhaust):	132.7 inches 337 cm
Weight:	14,660 lbs 6649 kg
