UTB/Universal 510
Type: Utility Tractors
Contents:
Production | |
| Manufacturer: | UTB/Universal |
| Type: | Utility tractor |
| Factory: | Brasov, Romania |
| Original price: | $10,500 (1990 ) |
| The Universal Farm Group of Rowlett, Texas sold this model as the Universal 550. | |
UTB/Universal 510 Power | |
| Drawbar (claimed): | 42 hp 31.3 kW |
| PTO (claimed): | 43 hp 32.1 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| 4x4 MFWD 4WD | |
| Final drives: | spur gear |
| Differential lock: | mechanical rear |
| Steering: | power |
| Brakes: | mechanical band |
| Cab: | Two-post ROPS. |
| Transmission: | 8-speed partially synchronized |
Hydraulics | |
| Type: | open center |
| Pressure: | 2133 psi 147.1 bar |
| Valves: | 1 |
| Pump flow: | 10 gpm 37.9 lpm |
Tractor hitch | |
| Rear Type: | II/I |
| Rear lift: | 3080 lbs 1397 kg |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Rear RPM: | 540 (1.375) |
| Engine RPM: | 540@2160 |
Engine Detail | |
| UTB | |
| diesel | |
| 3-cylinder | |
| liquid-cooled | |
| Displacement: | 164.9 ci 2.7 L |
| Bore/Stroke: | 4.016x4.33 inches 102 x 110 mm |
| Air cleaner: | oil bath |
| Compression: | 17:1 |
| Rated RPM: | 2400 |
| Starter volts: | 12 |
| Oil capacity: | 10.3 qts 9.7 L |
| Coolant capacity: | 14 qts 13.2 L |
Transmission | |
| Type: | partially synchronized |
| Gears: | 8 forward and 2 reverse |
| Clutch: | 279.4mm dry disc |
Dimensions | |
| 2WD Wheelbase: | 75.75 inches 192 cm |
| 4WD Wheelbase: | 78 inches 198 cm |
| 2WD Length: | 116.5 inches 295 cm |
| 4WD Length: | 122.5 inches 311 cm |
| 2WD Weight: | 4230 lbs 1918 kg |
| 4WD Weight: | 5350 lbs 2426 kg |
| 2WD Ground clearance: | 18.5 inches 46 cm |
| 4WD Ground clearance: | 15.5 inches 39 cm |
| 2WD Front tread: | 52 to 79 inches 132 to 200 cm |
| 4WD Front tread: | 55.3 inches 140 cm |
| Rear tread: | 47 to 75 inches 119 to 190 cm |
