TYM 2310

Production
Manufacturer:	TYM

TYM 2310 Power
Engine:	23.2 hp 17.3 kW
PTO (claimed):	18.4 hp 13.7 kW

Mechanical
Steering:	hydrostatic power
Brakes:	wet disc
Transmission:	12-speed

Capacity
Fuel:	8.7 gal 32.9 L
Hydraulic system:	8.5 gal 32.2 L

Hydraulics
Capacity:	8.5 gal 32.2 L
Pump flow:	6.1 gpm 23.1 lpm
Total flow:	9.4 gpm 35.6 lpm

Tractor hitch
Rear Type:	I
Rear lift (at ends):	2,078 lbs 942 kg

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	540

Electrical
Charging amps:	50

Engine Detail
Dae Dong TD1300
diesel
3-cylinder
liquid-cooled
Displacement:	79.3 ci 1.3 L
Power:	23.2 hp 17.3 kW
Rated RPM:	2700
Oil capacity:	6 qts 5.7 L
Coolant capacity:	7.4 qts 7.0 L

Transmission
Transmission:	sync shuttle
Gears:	12 forward and reverse

Dimensions
Wheelbase:	64 inches 162 cm
Length:	121 inches 307 cm
Width:	52 inches 132 cm
Height:	92 inches 233 cm
Weight:	3,000 lbs 1360 kg
Ground clearance:	12 inches 30 cm
