SAME Explorer 70
Type: Utility Tractors
Contents:
Production | |
| Manufacturer: | SAME |
| Type: | Utility tractor |
SAME Explorer 70 Power | |
| Engine: | 70 hp 52.2 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| 4x4 MFWD 4WD | |
| Differential lock: | mechanical rear |
| Steering: | power |
| Brakes: | hydraulic wet disc |
| Cab: | Four-post ROPS. Available cab with optional heater. |
| Transmissions: | 12-speed |
| 24-speed | |
Hydraulics | |
| Pressure: | 2600 psi 179.3 bar |
| Pump flow: | 8.7 gpm 32.9 lpm |
Tractor hitch | |
| Rear Type: | II |
| Control: | position and draft control |
| Rear lift: | 7562 lbs 3430 kg |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Clutch: | hydraulic wet disc |
| Rear RPM: | 540/1000 (1.375) |
Electrical | |
| Charging system: | alternator |
| Charging amps: | 64 |
| Battery volts: | 12 |
| Battery AH: | 110 |
Engine Detail | |
| SAME 1000 4-A | |
| diesel | |
| 4-cylinder | |
| air-cooled | |
| Displacement: | 244.1 ci 4.0 L |
| Bore/Stroke: | 4.13x4.55 inches 105 x 116 mm |
| Power: | 70 hp 52.2 kW |
| Air cleaner: | dry |
| Rated RPM: | 2350 |
| Starter: | electric |
| Starter volts: | 12 |
| Starter power: | 4 hp 3.0 kW |
Dimensions | |
| 2WD Wheelbase: | 91.5 inches 232 cm |
| 4WD Wheelbase: | 90 inches 228 cm |
| Length: | 157.1 inches 399 cm |
| Width: | 73.6 inches 186 cm *Minimum width |
| 2WD Ground clearance: | 19.3 inches 49 cm |
| 4WD Ground clearance: | 16.1 inches 40 cm |
| 2WD Front tread: | 55.1 to 78.7 inches 139 to 199 cm |
| 4WD Front tread: | 55.1 to 62.7 inches 139 to 159 cm |
| Rear tread: | 55.1 to 78.7 inches 139 to 199 cm |
