New Holland TJ450

Production: 2002 - 2005

Production
Manufacturer:	New Holland
Type:	Four-wheel Drive (4WD) tractor
Factory:	Fargo, North Dakota, USA
The New Holland TJ450 is the same as the Case IH STX450.

New Holland TJ450 Power
Engine:	450 hp 335.6 kW
PTO (claimed):	395 hp 294.6 kW
Drawbar (tested):	371.35 hp 276.9 kW
PTO (tested):	454.23 hp 338.7 kW

Mechanical
Chassis:	4x4 4WD
Steering:	hydrostatic power
Brakes:	integrated hydraulic wet disc
Cab:	Cab standard
Transmission:	16-speed full powershift

Hydraulics
Type:	closed center load sensing
Valves:	4 to 9
SCV flow:	35 gpm 132.5 lpm
Total flow:	40 gpm 151.4 lpm
55 gpm 208.2 lpm *Optional
90 gpm 340.7 lpm *Optional

Tractor hitch
Rear Type:	III, IVN
Rear lift:	19,500 lbs 8845 kg

Electrical
Ground:	negative
Charging amps:	135
Battery CCA:	1000

Engine Detail
Cummins QSX 15
turbocharged aftercooled diesel
6-cylinder
liquid-cooled
Displacement:	912 ci 14.9 L
Bore/Stroke:	5.394x6.654 inches 137 x 169 mm
Power:	450 hp 335.6 kW
Air cleaner:	dual paper elements
Compression:	16.5:1
Rated RPM:	2000
Torque:	1743 lb-ft 2363.5 Nm
Starter volts:	12
Oil capacity:	52 qts 49.2 L
Coolant capacity:	21.1 qts 20.0 L

Transmission
Type:	full powershift
Gears:	16 forward and 2 reverse

Dimensions
Wheelbase:	154 inches 391 cm
Length:	317.5 inches 806 cm
Height:	152.1 inches 386 cm
Operating weight:	39325 lbs 17837 kg
Ballasted weight:	44560 lbs 20212 kg
