New Holland 8870A
Type: Row-crop Tractors
Contents:
Production | |
| Manufacturer: | New Holland |
| Type: | Row-Crop tractor |
New Holland 8870A Power | |
| PTO (claimed): | 180 hp 134.2 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| 4x4 MFWD 4WD | |
| Differential lock: | electro-hydraulic |
| Steering: | power |
| Cab: | Cab standard with air-conditioning. |
| Transmission: | 16-speed full power shift |
Capacity | |
| Fuel: | 110 gal 416.4 L |
| Hydraulic system: | 37 gal 140.0 L |
Hydraulics | |
| Type: | closed center load-sensing |
| Capacity: | 37 gal 140.0 L |
| Pressure: | 3000 psi 206.8 bar |
| Valves: | 3 or 4 |
| Pump flow: | 31 gpm 117.3 lpm |
| 55 gpm 208.2 lpm *Optional | |
Tractor hitch | |
| Rear Type: | III |
| Control: | electronic draft sensing |
| Rear lift: | 14811 lbs 6718 kg |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Clutch: | wet disc |
| Rear RPM: | 1000 |
Electrical | |
| Ground: | negative |
| Charging system: | alternator |
| Charging amps: | 130 |
| Batteries: | 2 |
| Battery CCA: | 850 |
| Battery volts: | 12 |
Engine Detail | |
| New Holland | |
| turbocharged intercooled diesel | |
| 6-cylinder | |
| liquid-cooled | |
| Displacement: | 456 ci 7.5 L |
| Bore/Stroke: | 4.40x5.00 inches 112 x 127 mm |
| Compression: | 17.5:1 |
| Rated RPM: | 2100 |
| Starter: | electric |
| Starter volts: | 12 |
| Oil capacity: | 22.5 qts 21.3 L |
| Coolant capacity: | 28 qts 26.5 L |
Transmission | |
| Type: | full power shift |
| Gears: | 16 forward and 9 reverse |
Dimensions | |
| 2WD Wheelbase: | 118.3 inches 300 cm |
| 4WD Wheelbase: | 118.3 inches 300 cm |
| SuperSteer Wheelbase: | 122.6 inches 311 cm |
| Length: | 212 inches 538 cm |
| Height (cab): | 122 inches 309 cm |
| Height (exhaust): | 124 inches 314 cm |
| Ground clearance: | 18.6 inches 47 cm |
| Rear axle: | Bar: 4.13 by 112 inches 104 by 2844 mm |
| Rear axle: | Bar: 4.13 by 120 inches 104 by 3048 mm |
| 2WD Front tread: | 61 to 89 inches 154 to 226 cm |
| 4WD Front tread: | 60 to 89 inches 152 to 226 cm |
| SuperSteer Front tread: | 60 to 88 inches 152 to 223 cm |
