Mitsubishi MT300

Production: 1984 - 1991

Production
Manufacturer:	Mitsubishi

Variants
MT300:	2WD
MT300D:	4WD

Mitsubishi MT300 Power
Engine:	30 hp 22.4 kW
PTO (claimed):	26 hp 19.4 kW

Mechanical
Chassis:	4x2 2WD
4x4 MFWD 4WD
Differential lock:	rear standard
Steering:	manual
Steering:	power*Optional
Brakes:	wet disc
Cab:	Open operator station.
Transmissions:	9-speed synchromesh
hydrostatic

Hydraulics
Type:	open center
Pump flow:	5.7 gpm 21.6 lpm
Steering flow:	1.9 gpm 7.2 lpm

Tractor hitch
Rear Type:	I
Control:	position control
draft control*Optional

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	540/1000 (1.375)
Engine RPM:	540@2307 1000@2353

Electrical
Ground:	negative
Battery volts:	12

Engine Detail
Mitsubishi K3M
diesel
3-cylinder
liquid-cooled
Displacement:	91.3 ci 1.5 L
Bore/Stroke:	3.307x3.543 inches 84 x 90 mm
Power:	30 hp 22.4 kW
Air cleaner:	dry element
Rated RPM:	2700
Starter volts:	12

Dimensions
Wheelbase:	62 inches 157 cm
Length:	115.6 inches 293 cm
Width:	55.5 inches 140 cm
4WD Height:	55.9 inches 141 cm
2WD Height:	56.1 inches 142 cm
2WD Weight:	2337 lbs 1060 kg
4WD Weight:	2558 lbs 1160 kg
4WD Ground clearance:	10.8 inches 27 cm
2WD Ground clearance:	13.6 inches 34 cm
2WD Front tread:	42.5 to 52.6 inches 107 to 133 cm
4WD Front tread:	47.2 inches 119 cm
Rear tread:	39.9 to 60 inches 101 to 152 cm
