Massey Ferguson 6712

Production: 2017

Production
Manufacturer:	Massey Ferguson
Type:	Utility tractor

Massey Ferguson 6712 Power
Engine:	115 hp 85.8 kW
PTO (claimed):	100 hp 74.6 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Final drives:	internal planetary
Differential lock:	electro-hydraulic rear
Steering:	power
Brakes:	wet disc
Cab:	Two-post folding ROPS. Cab optional.
Transmission:	12-speed power shuttle

Hydraulics
Type:	open center
Valves:	2 or 3
Pump flow:	15.1 gpm 57.2 lpm
25.9 gpm 98.0 lpm *Optional, with additional 41L auxiliary pump.

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	540/540E/1000

Electrical
Ground:	negative
Charging system:	alternator
Charging amps:	80
Battery volts:	12

Engine Detail
AGCO Power
intercooled turbocharged diesel
4-cylinder
liquid-cooled
Displacement:	268.5 ci 4.4 L
Emissions:	Tier IV
Emission control:	selective catalytic reduction (SCR)
Power:	115 hp 85.8 kW
Maximum Power:	120 hp 89.5 kW
Fuel system:	high-pressure common rail direct injection
Rated RPM:	2200
Torque:	510 lb-ft 691.6 Nm
Torque RPM:	1500
Starter:	electric
Starter volts:	12

Transmission
Type:	power shuttle
Gears:	12 forward and reverse
Clutch:	wet disc

Dimensions
Wheelbase:	98.4 inches 249 cm
Width:	70.7 inches 179 cm *Minimum
ROPS Weight:	8840 lbs 4009 kg
Cab Weight:	9017 lbs 4090 kg
Rear axle:	Flange
