Massey Ferguson 415
Type: Utility Tractors
Contents:
Production | |
| Manufacturer: | Massey Ferguson |
| Type: | Utility tractor |
| Factory: | Canoas, Brazil |
Variants | |
| utility | |
| narrow |
Massey Ferguson 415 Power | |
| Engine: | 46 hp 34.3 kW |
| PTO (claimed): | 39.7 hp 29.6 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| 4x4 MFWD 4WD (optional) | |
| Steering: | hydrostatic power |
| Brakes: | wet disc |
| Cab: | Open operator station. Two-post ROPS optional with available canopy. |
| Transmission: | 8-speed sliding spur gear |
Hydraulics | |
| Pressure: | 3046 psi 210.0 bar |
| Pump flow: | 4.5 gpm 17.0 lpm |
Tractor hitch | |
| Rear Type: | II |
| Control: | draft, position, and response control |
Power Take-off (PTO) | |
| Rear PTO: | live |
| independent (optional) | |
| Rear RPM: | 540 (1.375) |
| Engine RPM: | 540@1900 |
Electrical | |
| Ground: | negative |
| Battery volts: | 12 |
Engine Detail | |
| Perkins AD3.152 | |
| diesel | |
| 3-cylinder | |
| liquid-cooled | |
| Displacement: | 152.7 ci 2.5 L |
| Bore/Stroke: | 3.60x5.00 inches 91 x 127 mm |
| Power: | 46 hp 34.3 kW |
| Fuel system: | direct injection |
| Rated RPM: | 2250 |
| Torque: | 133.5 lb-ft 181.0 Nm |
| Torque RPM: | 1350 |
| Starter: | electric |
| Starter volts: | 12 |
Transmission | |
| Type: | sliding spur gear |
| Gears: | 8 forward and 2 reverse |
Dimensions | |
| Wheelbase: | 78.7 inches 199 cm |
| Length: | 151.2 inches 384 cm |
| Height (ROPS): | 96.1 inches 244 cm |
| Height (exhaust): | 82.7 inches 210 cm |
| 2WD Shiping weight: | 4,475 lbs 2029 kg |
| 4WD Shiping weight: | 4,872 lbs 2209 kg |
