Massey Ferguson 263

Production: 1998 - 1999

Production
Manufacturer:	Massey Ferguson
Type:	Utility tractor
Factory:	Coventry, England
Original price:	$25,000 (1999)

Massey Ferguson 263 Power
Engine (net):	60 hp 44.7 kW
PTO (claimed):	53 hp 39.5 kW
Drawbar (tested):	42.4 hp 31.6 kW
PTO (tested):	53.0 hp 39.5 kW

Mechanical
Chassis:	4x2 2WD
4x4 MFWD 4WD
Steering:	hydrostatic power
Brakes:	independent wet disc
Cab:	Two-post folding ROPS.
Transmissions:	8-speed sliding gear
8-speed synchro shuttle

Capacity
Fuel:	12.6 gal 47.7 L
Hydraulic system:	11.4 gal 43.1 L

Hydraulics
Capacity:	11.4 gal 43.1 L
Pump flow:	9.5 gpm 36.0 lpm
13.9 gpm 52.6 lpm (optional)

Tractor hitch
Rear Type:	II/I

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	540

Electrical
Ground:	negative

Engine Detail
Perkins 903.27T
turbocharged diesel
3-cylinder
liquid-cooled
Displacement:	165 ci 2.7 L
Bore/Stroke:	3.74x5.00 inches 95 x 127 mm
Air cleaner:	dual paper elements
Compression:	17.3:1
Rated RPM:	2250
Starter volts:	12
Coolant capacity:	10.8 qts 10.2 L

Dimensions
Wheelbase:	75.1 inches 190 cm (2WD)
76.7 inches 194 cm (4WD)
Operating weight:	5,110 lbs 2317 kg
Front tread:	48 to 72 inches 121 to 182 cm (2WD)
Front tread:	51.4 to 63.6 inches 130 to 161 cm (4WD)
Rear tread:	56 to 84 inches 142 to 213 cm
