Massey Ferguson 1547

Production: 2005 - 2008

Production
Distributor:	Massey Ferguson
Manufacturer:	Iseki
Type:	Compact Utility tractor
Factory:	Matsuyama, Japan

Massey Ferguson 1547 Power
Engine (gross):	47 hp 35.0 kW
Gear PTO (claimed):	38 hp 28.3 kW
Hydro PTO (claimed):	36.5 hp 27.2 kW

Mechanical
Chassis:	4x2 2WD
4x4 MFWD 4WD
Brakes:	wet disc
Cab:	Two-post folding ROPS. Cab optional with air-conditioning.
Transmissions:	8-speed
hydrostatic
12-speed

Capacity
Fuel:	13.2 gal 50.0 L
Front axle:	9 qts 8.5 L

Hydraulics
Type:	open center
Valves:	2*Optional
Pump flow:	11.6 gpm 43.9 lpm
Total flow:	16.5 gpm 62.5 lpm
17.6 gpm 66.6 lpm (with PowerShuttle)
Steering flow:	4.9 gpm 18.5 lpm
6 gpm 22.7 lpm (with PowerShuttle)

Tractor hitch
Rear Type:	I
Rear lift (at ends):	3,483 lbs 1579 kg

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	540 (1.375)
Mid PTO:	independent*Optional
Mid RPM:	2000

Electrical
Ground:	negative
Charging system:	alternator
Battery volts:	12

Engine Detail
Iseki
diesel
4-cylinder
liquid-cooled
Displacement:	134 ci 2.2 L
Bore/Stroke:	3.43x3.62 inches 87 x 92 mm
Power (gross):	47 hp 35.0 kW
Rated RPM:	2600
Starter:	electric
Starter volts:	12
Oil capacity:	8.5 qts 8.0 L
Coolant capacity:	8 qts 7.6 L

Dimensions
Wheelbase:	75 inches 190 cm
Length:	132.7 inches 337 cm
Width:	66.1 inches 167 cm
Height:	90.7 inches 230 cm
Ground clearance:	14.8 inches 37 cm
Front tread:	52.8 inches 134 cm
Rear tread:	51.2 inches 130 cm
