Massey Ferguson 150
Contents:
Production | |
| Manufacturer: | Massey Ferguson |
| Factory: | Detroit, Michigan, USA |
| Original price: | $5,693 (1975 ) |
Variants | |
| Standard: | fixed wide-front |
| Wide Row Crop: | adjustable wide-front |
| Tricycle: | narrow row-crop front |
Massey Ferguson 150 Power | |
| Engine: | 45.5 hp 33.9 kW |
| Drawbar (claimed): | 33 hp 24.6 kW |
| PTO (claimed): | 38 hp 28.3 kW |
| Plows: | 3 |
| Drawbar (tested): | 33.07 hp 24.7 kW |
| PTO (tested): | 37.88 hp 28.2 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| Steering: | power |
| Brakes: | differential mechanical disc |
| Cab: | Open operator station. Two-post ROPS and canopy optional. |
| Transmissions: | 8-speed |
| 12-speed partial power shift | |
| 6-speed gear | |
Capacity | |
| Fuel: | 18.5 gal 70.0 L |
| Hydraulic system: | 8 gal 30.3 L |
Hydraulics | |
| Capacity: | 8 gal 30.3 L |
| Total flow: | 4.8 gpm 18.2 lpm |
Tractor hitch | |
| Rear Type: | I |
Power Take-off (PTO) | |
| Rear PTO: | live |
| independent (optional) | |
| Rear RPM: | 540 |
150 Serial Numbers | |
| Location: | Below instrument panel |
| 1964: | 642000003 |
| 1965: | 642000859 |
| 1966: | 642003946 |
| 1967: | 642005474 |
| 1967: | 9A1000 |
| 1968: | 9A39836 |
| 1969: | 9A63158 |
| 1970: | 9A87325 |
| 1971: | 9A107597 |
| 1972: | 9A128141 |
| 1973: | 9A152025 |
| 1974: | 9A179544 |
| 1975: | 9A207681 |
Engine Detail | |
| Perkins AD3.152 | |
| diesel | |
| 3-cylinder | |
| liquid-cooled | |
| Displacement: | 152.7 ci 2.5 L |
| Bore/Stroke: | 3.6x5.0 inches 91 x 127 mm |
| Power: | 45.5 hp 33.9 kW |
| Air cleaner: | oil bath |
| Compression: | 17.4:1 |
| Rated RPM: | 2000 |
| Torque: | 115 lb-ft 155.9 Nm |
| Torque RPM: | 1200 |
| Starter volts: | 12 |
| Oil capacity: | 6.3 qts 6.0 L |
| Coolant capacity: | 10.5 qts 9.9 L |
Dimensions | |
| Wheelbase: | 81.1 inches 205 cm |
| 84.3 inches 214 cm (tricycle) | |
| Length: | 131.5 inches 334 cm |
| Width: | 63.4 inches 161 cm |
| Height (steering wheel): | 65 inches 165 cm |
| Operating weight: | 4,805 lbs 2179 kg (diesel) |
| Ballasted weight: | 6,605 lbs 2996 kg (diesel) |
| Ground clearance: | 12.6 inches 32 cm |
| 15 inches 38 cm (wide row-crop) | |
| Front tread: | 48 to 72 inches 121 to 182 cm |
| Rear tread: | 48 to 76 inches 121 to 193 cm (manual) |
| Rear tread: | 52 to 72 inches 132 to 182 cm (power) |
